* All Dimensions in Inches
* L, W measured at Closed End of Enclosure
Arinc Style Metal Enclosures
| NORPIN PART NUMBER |
OUTSIDE WIDTH |
OUTSIDE LENGTH |
MAXIMUM HEIGHT |
BOTTOM RADIUS |
SIDE RADIUS |
MATERIAL THICKNESS |
|---|---|---|---|---|---|---|
| NA402-425.5S-ARINC | 4.796in 121.8184mm |
4.062in 103.1748mm |
6.500in 165.1mm |
0.250in 6.35mm |
0.093in 2.3622mm |
0.050in 1.27mm |
| NA403-426.5-ARINC | 4.828in 122.6312mm |
4.090in 103.886mm |
6.500in 165.1mm |
0.250in 6.35mm |
0.093in 2.3622mm |
0.063in 1.6002mm |
| NA306-306A-ARINC | 3.187in 80.9498mm |
3.187in 80.9498mm |
7.500in 190.5mm |
0.125in 3.175mm |
0.105in 2.667mm |
0.032in 0.8128mm |
| NA305.5-331-ARINC | 3.968in 100.7872mm |
3.175in 80.645mm |
6.375in 161.925mm |
0.109in 2.7686mm |
0.125in 3.175mm |
0.050in 1.27mm |
